Tianjin Lefin Industrial Co., Ltd is one of the most experienced manufacturers and suppliers of fbe coating steel pipe in China. Please feel free to buy high quality fbe coating steel pipe from our factory. Good service and reasonable price are available.
FBE COATING STEEL PIPE
Description: FBE:Single-layer fusion bonded epoxy
FBE Coating steel pipe, FBE Coating LSAW PIPE, FBE coating SSAW PIPE, FBE coating SMLS PIPE
Standard: DIN EN ISO 21809-2, ANSI/AWWA C213
DIN EN ISO 21809-2: Petroleum and natural gas industries-External coatings for buried or submerged pipelines used in pipeline transportation systems-Part 2: Fusion-bonded epoxy coatings
ANSI/AWWA C213: Fusion-bonded epoxy coatings and linings for steel water pipe and fittings
FBE Coating adopts special fusion bonded epoxy powder coating as film-forming material. This epoxy powder coating is a thermo setting coating, which is made of solid epoxy resin, curing agent and various additives through mixing and crushing. Before painting, the steel pipe shall be shot blasted and perheated by medium frequency, and then the epoxy powder coating shall be sprayed on the heated steel pipe surface by electrostatic spraying method. It shall be fused and bonded on the steel pipe surface and solidified to form a coating. FNE Coating is generally a one-time film-forming structure with a film thickness of 300-500μ m(above 12 mil).
FBE Coating for LSAW PIPE and SSAW PIPE:
| Product | LSAW PIPE/SSAW PIPE |
|
Standard |
EN10210, EN10217, EN10219, ASTM A252(Piling pipe), ASTM A572, ASTM A53, API5L |
| Grade |
S235, S275, S355JRH, S355J0H, S355J2H, GR.1, GR.2, GR.3, x12, x20 |
| Size | 16 INCH-64 INCH(406-1626MM) |
| Thickness |
6MM-80MM |
| Length | 12-12.2M |
Working Temperature: -30~100℃
Coating thickness: 300-1000μ m
Processing process:
1. Clean the steel pipe thoroughly to remove dirt, oil or other debris.
2. Apply a layer of epoxy primer to the pipe.
3. The FBE coating is applied using a special process called electrostatic spray deposition.
4. Heat it to high temperature to solidify and harden.
Advantages:
1. Corrosion protection: FBE coating is an excellent solution for protecting pipelines, tanks and other metal structures from corrosion.
2. High durability and lifespan: FBE coating has excellent durability and lifespan. It is resistant to abrasion, impact and other forms of wear, ensuring that the coating structure remains in good condition for many years.
3. Cost-effective: Compared with other coating materials, FBE coating is a cost-effective corrosion protection solution.
4. Easy to apply: FBE coating is easy to apply and can be applied by various methods such as spraying, dipping or brushing.
5. Environmentally friendly: FBE coating is an environmentally friendly solution because it does not contain volatile organic compounds (VOCs) and other harmful chemicals that may be released into the environment during application or use.
Application:
1. FBE coatings are suitable for use in areas where pipes are exposed to high humidity (such as coastal or humid environments).
2. FBE coatings are resistant to abrasion and impact damage and are suitable for applications where pipes are subject to mechanical stress, such as in underground or underwater environments.
3. FBE coatings are ideal for industries with strict environmental regulations, such as the oil and gas industry.
