Name: China Galvanized Scaffold Tubes Suppliers, Manufacturers, Factory - Good Price - Tianjin Lefin
Brand: Lefin
SKU: 180331844

Tianjin Lefin Industrial Co., Ltd is one of the most experienced manufacturers and suppliers of galvanized scaffold tubes in China. Please feel free to buy high quality galvanized scaffold tubes from our factory. Good service and reasonable price are available.

Galvanized Scaffold Tubes Specification

——————————————————————————————————————

Galvanized Scaffold Tubes Lengths: 0.3m to 6.3m length ( any cutting lengths you want)
Galvanized Scaffold Tubes Weight: OD 48.3*4mm -Per unit 4.37kg/2.937lbs,

OD 48.3*3.2mm -Per unit 3.56kg/2.392lbs

Galvanized Scaffold Tubes Quality standard: EN39/EN10219/BS1139/AS1163/MS1462
Galvanized Scaffold Tubes Finishing: Hot Dipped Galvanized Pipe or Black Bare Pipe, Ral Color Painted Ends
Galvanized Scaffold Tubes Zinc content: Standard: ≥40 Micron
Galvanized Scaffold Tubes End finish: Plain End or Painted available
Galvanized Scaffold Tubes Pack sizes: 37pcs or 61pcs /per bundle (some countires require 50 pcs or 91 pcs per bundle,also workable)
Galvanized Scaffold Tubes Other grade: JISG3444 STK 500 (Φ48.6 x 2.4 thk) SS311

Galvanized Scaffold Tubes HS Code:730840 or 730630 both ok.

Steel-Pipe

edc5ff93-f9e8-4cde-a6b4-834bfc8aacf8

Galvanized Scaffold Tubes Testing and Quality Control

——————————————————————————————————————

1. Product tested and in compliance to EN39/EN10219/BS1139/AS1163/MS1462.

Chemical Composition: Carbon, Silicon Phosphorus, Sulphur

Mechanical Properties: Tensile Stength, Yield Stress, Elongation

2. All tubes come supplied with Full Inspection /Certification & Mill Cert.

Tolerance

Wall thickness: +/-10%

Outside Diameter: +/-0.5mm

Inside Diameter -2.6mm

Mass, Single Tube 4.37kg/m +12% -8%

Mass,Batches of tubes 4.37kg/m, +/-7.5%

Upper Tolerance: governed by the tolerance on the mass.

Lower Tolerance: wall thickness shall be at least 3.6mm on type 4.0 tube. a tolerance of -15% being allowded in isolated places over a length not exceeding 100mm,but only if the decrease in thicnkess affects only the external surface.

Marking eg: Steel Tube-EN39-WB-4-E

Embossing Marking, NO marking, Painted Marking

3. Scaffold Tubes are compatible with all types of couplers and fittings and other scaffolding accessories.
4. All scaffolding pipes are loaded in bundles, three steel straps on each end of the bundle,& 2 straps in the middle. 2 white belts at the each end for loading and unloading purpose
5. Product Licence no & Sirim Standard marking.

Please consult the me for detailed product with quantity and size,

Call Me,Elva (mob/whatsapp/wechat) 0086-15122519420

or send me email: elvazhao@lefinsteel.com

Galvanized Scaffold Tubes 008615122519420 (5)

Galvanized Scaffold Tubes Packing and Shipping

——————————————————————————————————————

For the detailed package of black iron pipe we could do as bellow:
1. Bulk: Galvanized Scaffold Tubes warrped with plastic cloth.

2. 20GP and 40HQ
1) in bundle with steel strip
2) inside with bundle, outside with plastic cloth
3) by bulk, then put into container directly

3. For container
1)20FT GP Container: pipe length less than 5.85m, qty max 28.2tons
2)40FT GP or HQ Container: pipe length less than 12m, qty max 28.2tons

Galvanized Scaffold Tubes 008615122519420 (7)
